Produk
Merek: Baja huitong
Standar: bs, GB, ASTM, JIS, API
Bahan: A53-A369, Q195-Q345, ST35-ST52
Bentuk Bagian: Bulat
Tempat Asal: Cina
Aplikasi: Pipa Fluida, PIPA MINYAK, Pipa Struktur, Pipa gas
Proses Produksi: GERGAJI
Sertifikasi: ce, API
Apakah Paduan: Non-Paduan
Toleransi: ± 1%
Kategori: Pipa Baja Dilas
Layanan Pengolahan: Pembengkokan, Pengelasan, Pemotongan, Meninju, Dekorasi
Tolerance: ±1%
Kemasan: Standard Export Packaging
Steel Code / Steel Grade: A B X42 X46 X52 X56 X60 X65 X70
Length: 9m-12.3m (30'- 40') Or According to Customer Requirements
Executive Standard: API、DNV、ISO、DEP、EN、ASTM、DIN、BS、GB、CSA
Out Diameter: Φ508mm- 1118mm (20"- 44")
Wall Thickness: 6.0mm-30.0mm（1/4"-1"）
Nama Produk: UOE Steel Pipe
Kemasan: Kemasan ekspor standar atau sesuai dengan kebutuhan pelanggan
Produktivitas: 5000Tons Per Month
Transportasi: Ocean,Land,Express
Tempat asal: Cina
Dukungan tentang: 10000Tons Per Month
Kode HS: 7306309000
Jenis pembayaran: T/T,D/P,L/C
Inkoterm: FOB,CFR,CIF,EXW
Deskripsi Produk:
Pipa Baja LSAW (Pengelasan Pengelasan Lengkungan Longitudinal yang Disubreviated adalah istilah ekspresi profesional untuk pipa baja LSAW. Ini menggunakan pelat medium dan tebal tunggal sebagai bahan baku, dan pelat baja ditekan (digulung) ke dalam tabung yang kosong dalam cetakan atau a mesin pembentuk . Pipa las busur.
Menurut standar API, dalam pipa minyak dan gas besar, pipa las busur lurus terendam adalah satu -satunya jenis pipa yang berlaku saat melewati Kelas 1 dan Kelas 2
Area seperti zona alpine, dasar laut dan daerah perkotaan berpenduduk padat. Menurut cara pembentukan, itu dapat dibagi menjadi:
Pipa Welded UOE : Pelat baja lembaran di tepi pra-bending, setelah pembentukan U, pembentukan o, pengelasan internal, pengelasan eksternal, proses pengembangan dingin mekanis;
JCOE Welded Pipe : yaitu menurut pra-welding "jcoe", membentuk, setelah mengelas melalui ekstanding dingin dan proses lainnya;
HME Welded Pipe : Dibentuk oleh Metode Rolling Mandrel Menurut "CCO", setelah pengelasan, ia melewati Expanding Dingin dan proses lainnya
| Types | Standard | |||||
| SY/T5040-2000 | SY/T5037-2000 | SY/T9711.1-1977 | ASTM A252 | AWWA C200-97 | API 5L PSL1 | |
| Tube end OD deviation | ±0.5%D | ±0.5%D | -0.79mm~+2.38mm | <±0.1%T | <±0.1%T | ±1.6mm |
| Wall thickness | ±10.0%T | D<508mm, ±12.5%T | -8%T~+19.5%T | <-12.5%T | -8%T~+19.5%T | 5.0mm<T<15.0mm, ±0.11 |
| D>508mm, ±10.0%T | T≥15.0mm, ±1.5mm | |||||
| Standard | Grade | Chemical Composition(max)% | Mechanical Properties(min) | |||||
| C | Mn | Si | S | P | Yield Strength(Mpa) | Tensile Strength(Mpa) | ||
| GB/T700-2006 | A | 0.22 | 1.4 | 0.35 | 0.050 | 0.045 | 235 | 370 |
| B | 0.2 | 1.4 | 0.35 | 0.045 | 0.045 | 235 | 370 | |
| C | 0.17 | 1.4 | 0.35 | 0.040 | 0.040 | 235 | 370 | |
| D | 0.17 | 1.4 | 0.35 | 0.035 | 0.035 | 235 | 370 | |
| GB/T1591-2009 | A | 0.2 | 1.7 | 0.5 | 0.035 | 0.035 | 345 | 470 |
| B | 0.2 | 1.7 | 0.5 | 0.030 | 0.030 | 345 | 470 | |
| C | 0.2 | 1.7 | 0.5 | 0.030 | 0.030 | 345 | 470 | |
| BS En10025 | S235JR | 0.17 | 1.4 | - | 0.035 | 0.035 | 235 | 360 |
| S275JR | 0.21 | 1.5 | - | 0.035 | 0.035 | 275 | 410 | |
| S355JR | 0.24 | 1.6 | - | 0.035 | 0.035 | 355 | 470 | |
| DIN 17100 | ST37-2 | 0.2 | - | - | 0.050 | 0.050 | 225 | 340 |
| ST44-2 | 0.21 | - | - | 0.050 | 0.050 | 265 | 410 | |
| ST52-3 | 0.2 | 1.6 | 0.55 | 0.040 | 0.040 | 345 | 490 | |
| JIS G3101 | SS400 | - | - | - | 0.050 | 0.050 | 235 | 400 |
| SS490 | - | - | - | 0.050 | 0.050 | 275 | 490 | |
| API 5L PSL1 | A | 0.22 | 0.9 | - | 0.03 | 0.03 | 210 | 335 |
| B | 0.26 | 1.2 | - | 0.03 | 0.03 | 245 | 415 | |
| X42 | 0.26 | 1.3 | - | 0.03 | 0.03 | 290 | 415 | |
| X46 | 0.26 | 1.4 | - | 0.03 | 0.03 | 320 | 435 | |
| X52 | 0.26 | 1.4 | - | 0.03 | 0.03 | 360 | 460 | |
| X56 | 0.26 | 1.1 | - | 0.03 | 0.03 | 390 | 490 | |
| X60 | 0.26 | 1.4 | - | 0.03 | 0.03 | 415 | 520 | |
| X65 | 0.26 | 1.45 | - | 0.03 | 0.03 | 450 | 535 | |
| X70 | 0.26 | 1.65 | - | 0.03 | 0.03 | 585 | 570 | |
| STANDARDS | PRODUCTS | RANGES |
| IS:1239 (Part-I) | Mild Steel Tubes, Tubular | 15mm NB - 150mm NB |
| IS:1161 | Mild Steel Tubes for Structural purpose | 15mm NB - 200mm NB |
| IS:3601 | Mild Steel tubes for Mechanical & General Eng. purpose | 20mm x 0.80mm to 165.10 x 7.00 mm |
| IS:3589 | ERW Pipes for water Gas & Sewage | 168.3 x 4.00 mm to 219.1 x 7.00mm |
| IS:9295 | Steel Tubes for Idlers for Belt conveyors | 63.5 x 4.00 mm to 219.1 x 7.0 mm |
| IS:4270 | Steel Tubes for Water Wells | 114.3 x 5.00mm to 219.1mm x 7.1mm |
| IS:7138 | Steel Tubes for furniture | 20.0 x .60mm to 60.0 x 2.0mm |
| IS:4923 | Hollow Steel sections for structural purpose |
12.5 x 12.5 x 0.80 to 150 x 150 x 6.0mm 10 x 20 x 0.80mm to 150 x 200 x 6.0mm |
| IS:3074 | Steel Tubes for Automobile purpose | 19.7 x 1.00mm to 101.6 x 6.0mm |
| BS:1387 | Screwed & Socket Steel Tubes & Tubular | ½"NB to 6″NB 2.00 mm - 5.40 mm wall thick |
| BS:3601 | Steel Pipes & Tubes for pressure purpose | ½"NB to 6″NB 2.00 mm - 7.00 mm wall thickness |
| BS:6323 | Steel tubes for mechanical & general engineering purposes | 21.3″ to 219.1mm OD wall thickness-1.60-7.00 mm |
