Produk
Model No: Forged Threaded Flange
Merek: Huitong
Origin: Cina
Standar: Astm, bs, KERIUHAN, GB
Apakah Paduan: Non-Paduan
Toleransi: ± 1%
Layanan Pemrosesan: Pengelasan, Dekorasi, Meninju
Tolerance: ±1%
Size: 1/2” to 60”, DN 12mm to DN 1500mm
Pressure Class: Class 150 to Class 2,500, PN 2.5 to PN 250
Facing: RF / RTJ
Cabon Steel: A105, A350 LF2
Stainless Steel: A182 F304/F304L/F316/F316L/F321
Alloy Steel: F11, F12
Moq: 20PCS
Kemasan: Standard Export Packaging
Nama Produk: WN Flange
Kemasan: Kemasan Ekspor Standar
Produktivitas: 10000 Pieces Per Month
Transportasi: Ocean,Land,Air,Express,Others
Tempat asal: Cina
Dukungan tentang: 10000 Pieces Per Month
Kode HS: 3917400000
Jenis pembayaran: T/T,D/P,D/A,Paypal,Money Gram,Others
Inkoterm: FOB,CFR,CIF,EXW,CPT,CIP,DDP,DDU,DAF,Express Delivery
Flensa las-leher atau flensa leher lambang dapat dibedakan dari semua jenis flensa lainnya dengan hub yang panjang dan meruncing. Pipa yang dilas
Expander Flange adalah flensa pipa leher pengelasan di mana ukuran nominal ujung yang tidak diubah lebih besar dari ukuran nominal ujung yang bergelang. Mereka dapat digunakan untuk mengubah ukuran jalur pipa. Ini biasanya digunakan untuk meningkatkan ukuran garis ke ukuran pertama atau kedua yang lebih besar. Ini adalah alternatif untuk menggunakan kombinasi flensa peredam dan las yang terpisah. Flensa expander dapat digunakan untuk menghubungkan pipa ke pompa, kompresor, dan katup. Flensa dan perlengkapan pipa
Flensa leher las panjang NW biasanya disebut sebagai flensa hub tinggi. Ini dirancang untuk mentransfer tekanan ke pipa, sehingga mengurangi konsentrasi tegangan tinggi di dasar flensa. Pipa las
Spesifikasi flensa leher pengelasan: pipa baja
Ukuran: 1/2 "hingga 60", DN 12mm ke DN 1500mm
Kelas Tekanan: Kelas 150 hingga Kelas 2.500, PN 2.5 hingga PN 250
Menghadapi: RF / RTJ
Bahan flensa leher pengelasan:
Cabon Steel: A105, A350 LF2, C22.8, S355JR
Stainless Steel: A182 F304/F304L/F316/F316L/F321
Baja Paduan: F11, F12
Pengepakan: Casing kayu lapis dan palet kayu lapis
|
Product Name |
WN Flange |
|
Material |
Flange: 304 or 316L stainless steel O-rings: Viton, Buna, & silicone Fasteners: Wingnut, SureSeal, bulkhead & EVAC clamps Vacuum range Elastomer seal: >=1 x 10^-8 Torr - High vacuum EVAC metal seal: >=1 x 10^-11 Torr - UHV |
|
Size |
1/2” to 60”, DN 12mm to DN 1500mm |
|
Pressure Class |
Class 150 to Class 2,500, PN 2.5 to PN 250 |
|
Applications |
Blind Flanges are commonly used in petrochemical, pipe engineering, public services & water works. Blind pipe flanges are often used for high pressure applications. |
|
Delivery Time |
Usually within 7-10 days after receipt of advance payment |
|
Payment Terms |
T/T 30% Down Payment,Balance Will be Paid Before Shippment |
|
Advantage of Blind Flanges |
A much more cost efficient way to seal a pipe when doing repairs Blind flanges are convenient to install They can save a good amount of time and money |
| Nominal Pipe Size | Outside Diameter of Flange | Diameter of Raised Face | Thickness of Flanges Min. | Diameter of Bolt Circle | Diameter of Bolt Holes | Number of Bolts | Approximate Weight kgs |
| NPS | O | R | tf | W | I | n | |
| 1/2 | 90 | 34.9 | 9.6 | 60.3 | 15.9 | 4 | 0.44 |
| 3/4 | 100 | 42.9 | 11.2 | 69.9 | 15.9 | 4 | 0.64 |
| 1 | 110 | 50.8 | 12.7 | 79.4 | 15.9 | 4 | 0.90 |
| 1 1/4 | 115 | 63.5 | 14.3 | 88.9 | 15.9 | 4 | 1.13 |
| 1 1/2 | 125 | 73.0 | 15.9 | 98.4 | 15.9 | 4 | 1.50 |
| 2 | 150 | 92.1 | 17.5 | 120.7 | 19.1 | 4 | 2.38 |
| 2 1/2 | 180 | 104.8 | 20.7 | 139.7 | 19.1 | 4 | 4.09 |
| 3 | 190 | 127.0 | 22.3 | 152.4 | 19.1 | 4 | 4.97 |
| 3 1/2 | 215 | 139.7 | 22.3 | 177.8 | 19.1 | 8 | 6.20 |
| 4 | 230 | 157.2 | 22.3 | 190.5 | 19.1 | 8 | 7.18 |
| 5 | 255 | 185.7 | 22.3 | 215.9 | 22.2 | 8 | 8.83 |
| 6 | 280 | 215.9 | 23.9 | 241.3 | 22.2 | 8 | 11.55 |
| 8 | 345 | 269.9 | 27.0 | 298.5 | 22.2 | 8 | 20.07 |
| 10 | 405 | 323.8 | 28.6 | 362.0 | 25.4 | 12 | 28.87 |
| 12 | 485 | 381.0 | 30.2 | 431.8 | 25.4 | 12 | 44.18 |
| 14 | 535 | 412.8 | 33.4 | 476.3 | 28.6 | 12 | 59.07 |
| 16 | 595 | 469.9 | 35.0 | 539.8 | 28.6 | 16 | 76.36 |
| 18 | 635 | 533.4 | 38.1 | 577.9 | 31.8 | 16 | 94.51 |
| 20 | 700 | 584.2 | 41.3 | 635.0 | 31.8 | 20 | 123.94 |
| 24 | 815 | 692.2 | 46.1 | 749.3 | 34.9 | 20 | 187.90 |
| Norminal Pipe Size | O.D.of Flange, O | Min.Thick-ness of BL Flange, tf | Raised Fase Diam., R | Diam of Bolt Circle | No.of Bolt Holes | Diam.of Bolt Hole | Approxi-mate Weight kgs |
| 26 | 890 | 111.3 | 727 | 806.4 | 28 | 44.5 | 528.79 |
| 28 | 950 | 115.9 | 784 | 863.6 | 28 | 47.6 | 626.51 |
| 30 | 1020 | 127.0 | 841 | 927.1 | 28 | 50.8 | 789.17 |
| 32 | 1085 | 134.9 | 895 | 984.2 | 28 | 54.0 | 946.54 |
| 34 | 1160 | 144.2 | 953 | 1054.1 | 24 | 60.3 | 1158.72 |
| 36 | 1215 | 150.9 | 1010 | 1104.9 | 28 | 60.3 | 1323.63 |
Kategori Produk : Baja Struktural > Flensa dan perlengkapan pipa
