Produk
Model No: Flange
Merek: Huitong
Standar: Astm, bs, KERIUHAN, GB
Apakah Paduan: Non-Paduan
Toleransi: ± 1%
Layanan Pemrosesan: Pengelasan, Dekorasi, Meninju
Tolerance: ±1%
Nama Produk: Blind Flanges
Size: 1/2” to 60”, DN 12mm to DN 1500mm
Pressure Class: Class 150 to Class 2,500, PN 2.5 to PN 250
Facing: RF / RTJ
Cabon Steel: A105, A350 LF2
Stainless Steel: A182 F304/F304L/F316/F316L/F321
Alloy Steel: F11, F12
Moq: 20PCS
Kemasan: Standard Export Packaging
Kemasan: Kemasan Ekspor Standar
Produktivitas: 10000 Pieces Per Month
Transportasi: Ocean,Land,Air,Express,Others
Tempat asal: Cina
Dukungan tentang: 10000 Pieces Per Month
Kode HS: 3917400000
Jenis pembayaran: T/T,D/P,D/A,Paypal,Money Gram,Others
Inkoterm: FOB,CFR,CIF,EXW,CPT,CIP,DDP,DDU,DAF,Express Delivery
Flensa ini digunakan sebagai titik terminasi ke sistem perpipaan. Flange buta memiliki permukaan kosong dengan titik baut agar sesuai dengan pipa.
Flange JPI Kelas 150 BL RF A20 B3 Pipa Flensa dan Fitting
Flensa buta digunakan untuk menutup ujung sistem perpipaan. Ini adalah semacam pelat bundar tanpa pegangan tengah tetapi dengan semua lubang baut yang tepat. Flensa buta ini tersedia dalam berbagai ukuran dan bahan dan digunakan untuk memberikan positif lebih dekat pada ujung pipa, katup atau nozel peralatan. Flensa ini membantu akses mudah ke jalur setelah disegel. Flensa buta terkadang dibuat khusus atau dikerjakan untuk menerima pipa berukuran nominal yang sedang dibuat.
Flensa buta biasanya digunakan dalam petrokimia, teknik pipa, layanan publik & pekerjaan air.
Flensa pipa buta sering digunakan untuk aplikasi bertekanan tinggi.
Pengurangan ini dapat berupa pengurangan berulir atau pengurangan yang dilas.
Ukuran: 1/2 "hingga 60", DN 12mm ke DN 1500mm
Kelas Tekanan: Kelas 150 hingga Kelas 2.500, PN 2.5 hingga PN 250
Menghadapi: RF / RTJ
Bahan: Pipa yang Luas
Cabon Steel: A105, A350 LF2
Stainless Steel: A182 F304/F304L/F316/F316L/F321
Baja Paduan: F11, F12
Product Name |
Blind Flanges |
Material |
Cabon steel: A105, A350 LF2 Stainless steel: A182 F304/F304L/F316/F316L/F321 Alloy steel: F11, F12 |
Size |
1/2” to 60”, DN 12mm to DN 1500mm |
Pressure Class |
Class 150 to Class 2,500, PN 2.5 to PN 250 |
Applications |
Blind Flanges are commonly used in petrochemical, pipe engineering, public services & water works. Blind pipe flanges are often used for high pressure applications. |
Delivery Time |
Usually within 7-10 days after receipt of advance payment |
Payment Terms |
T/T 30% Down Payment,Balance Will be Paid Before Shippment |
Advantage of Blind Flanges |
A much more cost efficient way to seal a pipe when doing repairs Blind flanges are convenient to install They can save a good amount of time and money |
Nominal Pipe Size | Outside Diameter of Flange | Diameter of Raised Face | Thickness of Flanges Min. | Diameter of Bolt Circle | Diameter of Bolt Holes | Number of Bolts | Approximate Weight kgs |
NPS | O | R | tf | W | I | n | |
1/2 | 90 | 34.9 | 9.6 | 60.3 | 15.9 | 4 | 0.44 |
3/4 | 100 | 42.9 | 11.2 | 69.9 | 15.9 | 4 | 0.64 |
1 | 110 | 50.8 | 12.7 | 79.4 | 15.9 | 4 | 0.90 |
1 1/4 | 115 | 63.5 | 14.3 | 88.9 | 15.9 | 4 | 1.13 |
1 1/2 | 125 | 73.0 | 15.9 | 98.4 | 15.9 | 4 | 1.50 |
2 | 150 | 92.1 | 17.5 | 120.7 | 19.1 | 4 | 2.38 |
2 1/2 | 180 | 104.8 | 20.7 | 139.7 | 19.1 | 4 | 4.09 |
3 | 190 | 127.0 | 22.3 | 152.4 | 19.1 | 4 | 4.97 |
3 1/2 | 215 | 139.7 | 22.3 | 177.8 | 19.1 | 8 | 6.20 |
4 | 230 | 157.2 | 22.3 | 190.5 | 19.1 | 8 | 7.18 |
5 | 255 | 185.7 | 22.3 | 215.9 | 22.2 | 8 | 8.83 |
6 | 280 | 215.9 | 23.9 | 241.3 | 22.2 | 8 | 11.55 |
8 | 345 | 269.9 | 27.0 | 298.5 | 22.2 | 8 | 20.07 |
10 | 405 | 323.8 | 28.6 | 362.0 | 25.4 | 12 | 28.87 |
12 | 485 | 381.0 | 30.2 | 431.8 | 25.4 | 12 | 44.18 |
14 | 535 | 412.8 | 33.4 | 476.3 | 28.6 | 12 | 59.07 |
16 | 595 | 469.9 | 35.0 | 539.8 | 28.6 | 16 | 76.36 |
18 | 635 | 533.4 | 38.1 | 577.9 | 31.8 | 16 | 94.51 |
20 | 700 | 584.2 | 41.3 | 635.0 | 31.8 | 20 | 123.94 |
24 | 815 | 692.2 | 46.1 | 749.3 | 34.9 | 20 | 187.90 |
Norminal Pipe Size | O.D.of Flange, O | Min.Thick-ness of BL Flange, tf | Raised Fase Diam., R | Diam of Bolt Circle | No.of Bolt Holes | Diam.of Bolt Hole | Approxi-mate Weight kgs |
26 | 890 | 111.3 | 727 | 806.4 | 28 | 44.5 | 528.79 |
28 | 950 | 115.9 | 784 | 863.6 | 28 | 47.6 | 626.51 |
30 | 1020 | 127.0 | 841 | 927.1 | 28 | 50.8 | 789.17 |
32 | 1085 | 134.9 | 895 | 984.2 | 28 | 54.0 | 946.54 |
34 | 1160 | 144.2 | 953 | 1054.1 | 24 | 60.3 | 1158.72 |
36 | 1215 | 150.9 | 1010 | 1104.9 | 28 | 60.3 | 1323.63 |
