Produk
Model No: BS EN 10216-2
Merek: Shandong Huitong Steel Co., Ltd
Standar: ASTM
Bahan: 10Cr9Mo1VNb, Paduan Mn-V, ST35-ST52, Paduan Cr-Mo, A53-A369, Q195-Q345, 15NiCuMoNb5, 10 # -45 #, Paduan CrNi
Bentuk Bagian: Bulat, Persegi panjang, Lonjong, LTZ, Kotak
Tempat Asal: Cina
Aplikasi: Pipa Fluida, Pipa Boiler, Pipa Bor, Pipa Hidrolik, Pipa gas, PIPA MINYAK, Pipa Pupuk Kimia, Pipa Struktur
Proses Produksi: Ditarik Dingin
Sertifikasi: ce
Pengobatan Permukaan: Dilapisi tembaga, Galvanis
Tabung Khusus: Pipa EMT, Pipa Dinding Tebal
Apakah Paduan: Apakah Paduan
Toleransi: ± 1%
Kategori: Tabung Persegi, Pipa Dilas Spiral, Pipa Baja Dilas, Pipa Baja Seamless
Layanan Pengolahan: Pembengkokan, Pengelasan, Meninju, Pemotongan
Sizes: 1/2” to 24”
Wall Thickness: SCH 40, SCH STD, SCH 80, SCH XS, SCH 160
Length: 5.8M,6M,11.8M,12M or customized
Ends: PE (Plain End), BE (Beveled Ends)
Pengobatan permukaan: Polished, Varnished,, Polished, Varnished, 3PE, FBE
Standard And Grades: ASTM A335 / ASME SA335 Grade P11, P22, P5, P9,P91
Waktu pengiriman: 7-14 days
Manufacturing Types: Hot Rolled OR Cold Drawn
Kode HS: 7304191000
Kemasan: Kemasan Standar
Produktivitas: 5000TONS PER MONTH
Transportasi: Ocean,Land,Express,Others
Tempat asal: Cina
Dukungan tentang: 5000TONS PER MONTH
Kode HS: 7304191000
Jenis pembayaran: L/C,T/T,D/P,Paypal,Others
Inkoterm: FOB,CFR,CIF,Express Delivery,DDP
| Steel grade | C | Si | Mn | P | S | Cr b | Mo b | Ni b | Al tot |
Cu b c |
Nb b |
Cr+Cu +Mo+Ni |
|
| Steel name | Steel number | max. | max. | max. | Max. | max. | max. | max. | max. | min. | max. | max. | max. b |
| P195TR1 | 1.0107 | 0,13 | 0,35 | 0,70 | 0,025 | 0,020 | 0,30 | 0,08 | 0,30 | - | 0,30 | 0,010 | 0,70 |
| P195TR2 | 1.0108 | 0,13 | 0,35 | 0,70 | 0,025 | 0,020 | 0,30 | 0,08 | 0,30 | 0,02 d | 0,30 | 0,010 | 0,70 |
| P235TR1 | 1.0254 | 0,16 | 0,35 | 1,20 | 0,025 | 0,020 | 0,30 | 0,08 | 0,30 | - | 0,30 | 0,010 | 0,70 |
| P235TR2 | 1.0255 | 0,16 | 0,35 | 1,20 | 0,025 | 0,020 | 0,30 | 0,08 | 0,30 | 0,02 d | 0,30 | 0,010 | 0,70 |
| P265TR1 | 1.0258 | 0,20 | 0,40 | 1,40 | 0,025 | 0,020 | 0,30 | 0,08 | 0,30 | - | 0,30 | 0,010 | 0,70 |
| P265TR2 | 1.0259 | 0,20 | 0,40 | 1,40 | 0,025 | 0,020 | 0,30 | 0,08 | 0,30 | 0,02 d | 0,30 | 0,010 | 0,70 |
| Steel grade | Tensile properties | Impact properties | ||||||||
| Steel name | Steel number | Upper yield strength ReH b min. for Wall Thickness T mm | Tensile Strength Rm |
Elongation A min. % b c |
Minimum average absorbed energy KV J at a temperature of °C c | |||||
| T =16 | 16 < T =40 | 40 < T =60 | l | t | ||||||
| Mpa | Mpa | Mpa | Mpa | l | t | 0 | -10 | 0 | ||
| P195TR1 e | 1.0107 | 195 | 185 | 175 | 320 to 440 | 27 | 25 | - | - | - |
| P195TR2 | 1.0108 | 195 | 185 | 175 | 320 to 440 | 27 | 25 | 40 | 28 d | 27 |
| P235TR1 e | 1.0254 | 235 | 225 | 215 | 360 to 500 | 25 | 23 | - | - | - |
| P235TR2 | 1.0255 | 235 | 225 | 215 | 360 to 500 | 25 | 23 | 40 | 28 d | 27 |
| P265TR1 e | 1.0258 | 265 | 255 | 245 | 410 to 570 | 21 | 19 | - | - | - |
| P265TR2 | 1.0259 | 265 | 255 | 245 | 410 to 570 | 21 | 19 | 40 | 28 d | 27 |
|
Alloy steel pipe
Standard & Mate
|
GB5310-2013 Standard: 20G,25MnG, 15MoG,15CrMoG, 20MoG, 12CrMoG, 12Cr2MoG, 12Cr1MoVG, 12Cr2MoWVTiB, 10Cr9Mo1VNb, 15CrMoG, 10CrMo910 ASTM A209M/AS-209M Standard: A209T1/SA209 T1, A209 T1b/SA-209 T1b, A209T1a/SA209 T1a ASTM A213M/ASME SA 213 M Standard: T2, T5, T9, T11, T12, T22, T23, T24, T91, T911, T92, T122 ASTM A333M/ASME SA-333/SA333M Standard: Gr1, Gr3, Gr4, Gr6, Gr7,Gr8, Gr9, Gr10, Gr11 ASTM A334M/ASME SA-334/SA334M Standard: Gr1, Gr3, Gr6, Gr7,Gr8, Gr9, Gr11 ASTM A335/ASME SA335 Standard: P1, P2, P5,P5b, P5c, P9, P11, P12,P21,P22,P23, P24, P91, P92 ASTM A519 Standard: 4118, 4130,4135,4137,4140 ASTM A691 Standard: GRADE 91, CM65, CM70, CM75, CMSH70, CMS75, CMSH80, ASTM A691 Standard GRADE 1/2 Cr, GRADE 1CR, GRADE 1 1/4 CR, 2 1/4 Cr, 3CR, 5CR, 9 CR DIN17175 Standard: ST35.8, ST45.8, 15Mo3, 13CrMo44, 10CrMo910, 14MoV63,12Cr1MoV EN10216-2 Standard: P195GH, P235GH, P265GH, 13CrMo4-5, 10CrMo9-10, 16Mo3, 10CrMo5-5, X10CrMoVNb9-1 JIS G3458 Standard: STPA12, STPA20, STPA22, STPA23, STPA24, STPA25, STPA26 JIS G3441 Standard:SCR420 TK,SCM415 TK, SCM418 TK, SCM420TK, SCM430TK, SCM435TK, SCM440TK. NF A49-213/215 Standard: TU15D3, TU13CD4-04, TU10CD910, TUZ10CD505 Alloy C276 BS3059 Standard: S1-622-440, S2-622-440, S1-622-490, S2-622-490, S1-629-470, S2-629-470, S2-629-590 BS3604Standard: HFS625 CFS625 BS3606Standard: CFS625GB5310-2013 Standard: 20G,25MnG, 15MoG,15CrMoG, 20MoG, 12CrMoG, 12Cr2MoG, 12Cr1MoVG, 12Cr2MoWVTiB, 10Cr9Mo1VNb, 15CrMoG, 10CrMo910 ASTM A209M/AS-209M Standard: A209T1/SA209 T1, A209 T1b/SA-209 T1b, A209T1a/SA209 T1a ASTM A213M/ASME SA 213 M Standard: T2, T5, T9, T11, T12, T22, T23, T24, T91, T911, T92, T122 ASTM A333M/ASME SA-333/SA333M Standard: Gr1, Gr3, Gr4, Gr6, Gr7,Gr8, Gr9, Gr10, Gr11 ASTM A334M/ASME SA-334/SA334M Standard: Gr1, Gr3, Gr6, Gr7,Gr8, Gr9, Gr11 ASTM A335/ASME SA335 Standard: P1, P2, P5,P5b, P5c, P9, P11, P12,P21,P22,P23, P24, P91, P92 ASTM A519 Standard: 4118, 4130,4135,4137,4140 ASTM A691 Standard: GRADE 91, CM65, CM70, CM75, CMSH70, CMS75, CMSH80, ASTM A691 Standard GRADE 1/2 Cr, GRADE 1CR, GRADE 1 1/4 CR, 2 1/4 Cr, 3CR, 5CR, 9 CR DIN17175 Standard: ST35.8, ST45.8, 15Mo3, 13CrMo44, 10CrMo910, 14MoV63,12Cr1MoV EN10216-2 Standard: P195GH, P235GH, P265GH, 13CrMo4-5, 10CrMo9-10, 16Mo3, 10CrMo5-5, X10CrMoVNb9-1 JIS G3458 Standard: STPA12, STPA20, STPA22, STPA23, STPA24, STPA25, STPA26 JIS G3441 Standard:SCR420 TK,SCM415 TK, SCM418 TK, SCM420TK, SCM430TK, SCM435TK, SCM440TK. NF A49-213/215 Standard: TU15D3, TU13CD4-04, TU10CD910, TUZ10CD505 Alloy C276 BS3059 Standard: S1-622-440, S2-622-440, S1-622-490, S2-622-490, S1-629-470, S2-629-470, S2-629-590 BS3604Standard: HFS625 CFS625 BS3606Standard: CFS625 |
| Alloy steel pipe Size |
O.D:6-760mm
W.T:1-80mm
Fixed Length: 5.8m, 6m, 11.8m, 12m, or random length as required.
|
Kisaran pasokan kami untuk pipa baja; Salah satunya adalah pipa baja sml draw dingin, yang lain adalah pipa baja sml gulung panas,pipa minyakkami dapat menyediakanASTMA106 A53 A161 A179 A192 A500 A501Pipa Baja Galvanis Itu juga dapat dibuat,kami adalah produsen Cina dengan pengalaman ekspor yang kaya, pipa yang dilas Stainless/Seamless/Galvanized/Spiral/Welded/Copper/Oil/Casing/Alloy/Square/Round/Aluminium/Precision/Black, jika Anda membutuhkan flensa dan fiting pipa, silakan hubungi saya.
